Assignment Description

This exercise is intended to facilitate project brainstorming and team formation. Please see the videos linked below for guidance on brainstorming to find problems and engineering solutions to those problems.

In the first lecture, the course staff will assign you into groups of approximately 8 students to work on this assignment. These are not the groups or projects you will be working with on your course project, they are strictly for this assignment!. Each brainstorming group will use the brainstorming methods outlined in the videos above to come up with problem statements and corresponding solutions. This ideation exercise is intended to stimulate the process of finding a suitable senior design project for this semester but not all problem statements or proposed solutions may fit within the scope of ECE 445.

After the first lecture, all students must make a post on the Web Board. This initial post must consist of either a problem statement or a proposed solution and may be posted as a reply to an existing thread.

Requirements and Grading

Grading will be out of 5 total points and awarded based on the existence of substantive post on the Web Board ("Hello world" type posts will not receive credit).

Submission and Deadlines

The initial Web Board post is due by 11:59pm on the date listed on the Course Calendar. All students must either create or respond to a post. Students posting after the deadline will not receive credit.

Electronic Mouse (Cat Toy)

Jack Casey, Chuangy Zhang, Yingyu Zhang

Electronic Mouse (Cat Toy)

Featured Project

# Electronic Mouse (Cat Toy)

# Team Members:

- Yingyu Zhang (yzhan290)

- Chuangy Zhang (czhan30)

- Jack (John) Casey (jpcasey2)

# Problem Components:

Keeping up with the high energy drive of some cats can often be overwhelming for owners who often choose these pets because of their low maintenance compared to other animals. There is an increasing number of cats being used for service and emotional support animals, and with this, there is a need for an interactive cat toy with greater accessibility.

1. Get cats the enrichment they need

1. Get cats to chase the “mouse” around

1. Get cats fascinated by the “mouse”

1. Keep cats busy

1. Fulfill the need for cats’ hunting behaviors

1. Interactive fun between the cat and cat owner

1. Solve the shortcomings of electronic-remote-control-mouses that are out in the market

## Comparison with existing products

- Hexbug Mouse Robotic Cat Toy: Battery endurance is very low; For hard floors only

- GiGwi Interactive Cat Toy Mouse: Does not work on the carpet; Not sensitive to cat touch; Battery endurance is very low; Can't control remotely

# Solution

A remote-controlled cat toy is a solution that allows more cat owners to get interactive playtime with their pets. With our design, there will be no need to get low to the ground to adjust it often as it will go over most floor surfaces and in any direction with help from a strong motor and servos that won’t break from wall or cat impact. To prevent damage to household objects it will have IR sensors and accelerometers for use in self-driving modes. The toy will be run and powered by a Bluetooth microcontroller and a strong rechargeable battery to ensure playtime for hours.

## Subsystem 1 - Infrared(IR) Sensors & Accelerometer sensor

- IR sensors work with radar technology and they both emit and receive Infrared radiation. This kind of sensor has been used widely to detect nearby objects. We will use the IR sensors to detect if the mouse is surrounded by any obstacles.

- An accelerometer sensor measures the acceleration of any object in its rest frame. This kind of sensor has been used widely to capture the intensity of physical activities. We will use this sensor to detect if cats are playing with the mouse.

## Subsystem 2 - Microcontroller(ESP32)

- ESP32 is a dual-core microcontroller with integrated Wi-Fi and Bluetooth. This MCU has 520 KB of SRAM, 34 programmable GPIOs, 802.11 Wi-Fi, Bluetooth v4.2, and much more. This powerful microcontroller enables us to develop more powerful software and hardware and provides a lot of flexibility compared to ATMegaxxx.

Components(TBD):

- Product: [https://www.digikey.com/en/products/detail/espressif-systems/ESP32-WROOM-32/8544298](url)

- Datasheet: [http://esp32.net](url)

## Subsystem 3 - App

- We will develop an App that can remotely control the mouse.

1. Control the mouse to either move forward, backward, left, or right.

1. Turn on / off / flashing the LED eyes of the mouse

1. keep the cat owner informed about the battery level of the mouse

1. Change “modes”: (a). keep running randomly without stopping; (b). the cat activates the mouse; (c). runs in cycles(runs, stops, runs, stops…) intermittently (mouse hesitates to get cat’s curiosity up); (d). Turn OFF (completely)

## Subsystem 4 - Motors and Servo

- To enable maneuverability in all directions, we are planning to use 1 servo and 2 motors to drive the robotic mouse. The servo is used to control the direction of the mouse. Wheels will be directly mounted onto motors via hubs.

Components(TBD):

- Metal Gear Motors: [https://www.adafruit.com/product/3802](url)

- L9110H H-Bridge Motor Driver: [https://www.adafruit.com/product/4489](url)

## Subsystem 5 - Power Management

- We are planning to use a high capacity (5 Ah - 10 Ah), 3.7 volts lithium polymer battery to enable the long-last usage of the robotic mouse. Also, we are using the USB lithium polymer ion charging circuit to charge the battery.

Components(TBD):

- Lithium Polymer Ion Battery: [https://www.adafruit.com/product/5035](url)

- USB Lithium Polymer Ion Charger: [https://www.adafruit.com/product/259](url)

# Criterion for Success

1. Can go on tile, wood, AND carpet and alternate

1. Has a charge that lasts more than 10 min

1. Is maneuverable in all directions(not just forward and backward)

1. Can be controlled via remote (App)

1. Has a “cat-attractor”(feathers, string, ribbon, inner catnip, etc.) either attached to it or drags it behind (attractive appearance for cats)

1. Retains signal for at least 15 ft away

1. Eyes flash

1. Goes dormant when caught/touched by the cats (or when it bumps into something), reactivates (and changes direction) after a certain amount of time

1. all the “modes” worked as intended
