Let us analyse the stress field in this cantilever beam problem:
Choose the coordinates of the point in which you want to obtain the state of plane stress (at the plane z = 0):
x = | x = 0 mm |
y = | y = 0 mm |
The state of plane stress at this point is represented by the element below.
Angle: | θ= 0 o |
